Description

Magnet Cableless Digital Dance floor is excellent designed for stage, very suitable for mobile dj, it is light weight and easy to setup.

Features:
Cableless magnetic connection, very simple, convenient, fast and safe to install. easy to carry.

Specification:
Control mode: SD control with DMX512, sounds active, PC control ( Madrix acceptable)
Dimension(mm): L600*W600*H43mm ( 2x2 feet)
Light source: 8x8 SMD5050 3in 1 board
Max power: 20W
Input voltage:100-240v AC
Net Weight: 13.2KG (26.4lbs)
Resolution（L*W）: 8*8
Surface material: Tempered glass
Base housing material: metal
Bearing weight: 500KG/m2
Protection level: IP55
Visual angle: 120°
Working temperature: -20~ +45℃
Lifespan: ≥50，000 hours

Installation:
One dance floor structure:

After installation:
