ArtFox Beam 15R Extreme

  Listed in category:Professional Stage Lighting >> Moving Head                  <<Previous    Next>>
ArtFox Beam 15R Extreme
ArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R ExtremeArtFox Beam 15R Extreme

Related Resource:


Catalogue

Manual

Library

Name:     ArtFox Beam 15R Extreme
Style:      beam spot wash 3-in-1
Add to Cart:
Inquiry now:
Your email:
Your Name:
Your phone number:
Your Skype:
Your Address:
Your message:



Description:

ArtFox Beam 15R Extreme Video 1

see on youtube>>
ARTFOX Beam 15R Extreme is the evolution in extreme Beam moving heads. With evolution optics, adding Two level Zoom+ Focus+ Gobo wheel + 16 faced prism + frost function and faster movements speeds, this unit is the unique successful model combing spot and beam function 2-in-1. Three phase motors for all effects give it its new extreme speed effect and the new advance optical design will make your impressive.

Product Features:

• 330W YODN 15R Beam Extreme Optics and speed output
• 3 phase motors improved movement speed, 8/16 bit. - PAN = 2.14 sec
- TILT = 1.13 sec (Original Sharpy: Pan= 2.45 sec, Tilt=1.3 sec)
• 16 Facet Rotating Prism + Two Zoom + Focus + frost+ Variable speed Shutter / Strobe
• 280k lux @ 10m
• Beam Angle: from 0-8 degree
• 7 replaceable Rotating Indexing Gobos
• 7 Colors Index
• Linear Frost
• Linear dimming


Technical Specifications:

• 7 Static Dichroic Colors+White ,1 gobo wheel with 8 metal indexing, rotating and interchangeable gobos ,14/6 mm gobo size
• beam angle from 0-8 degree.
• dimmer and strobe, Two level zoom. foucs +16 facet rotating prism.
• AC 100-240V, 50/60 HZ
•Voltage: AC AC 100-240V, 50/60 HZ
•Lamp: YODN 15R, 330w Nominal luminous flux: 15,000 lm- Average rated life: 1,500 h
• 450W power consumption
• 280k Lux at 10M
• 18 DMX channels
• Movement, 8 bit, Maximum speeds:
- PAN = 2.14 sec
- TILT = 1.13 sec
• 3 pin or 5 pin DMX connectors
• IP20
• Cooling: 1 roller fan +3 fan
• MSD Platinum 15R lamp
• 18.5 kg (40.8 lbs)
• Dimensions: 42x35x56cm(16.5’’x13.78’’x22’’)
• CE,Rosh approved.
