Vista 17R

  Listed in category:Professional Stage Lighting >> Moving Head                  <<Previous    Next>>
Vista 17R
Vista 17RVista 17RVista 17R

Related Resource:


Catalogue

Manual

Library

Name:     Vista 17R
Style:      Super Bright, beam spot wash 3-in-1, 3D effects
Add to Cart:
Inquiry now:
Your email:
Your Name:
Your phone number:
Your Skype:
Your Address:
Your message:



Description:

Vista 17R Video 1

see on youtube>>
Vista 16R is an unique design Hybrid moving head Spot/Beam/Wash, which is powered by revolutionary 16R discharge lamps technology ( 8000k, 1,500hours). The powerful 16R has awesome output with 3 times the output of beam 230w,It comparable with Beam 440W on the market
What’s more, The ARTFOX Hybrid 16R Extreme features 16-facet and 6-facet lineal rotating prisms, motorized zoom and motorized focus, frost filter for wash effects, rotation replaceable gobo and static gobo wheel. It features 3 phase motor to provide faster ,precise movement on Pan/Tilt.

Features:

1. Unique Design 16R moving head Hybrid Spot/Beam/Wash, 3 in 1
2. Motorized Zoom from 0- 33 degree , From narrow beam to spot
3. Ultra bright output, Over 795,000 lux @ 16 feet, It is comparable with beam 440w.
4. Frost Filter for wash effect and frost effects
5. Double Prisms: 16- facet prism and 6-facet prism, ( 8 facet prism is for optional as well)
6. Prisms Rotating and Prisms macroseffects
7. Motorized Focus , Mechanical strobe and dimming from 0-100%
8. LCD 4 button Menu System

Specifications:

Lamps: The standard is Ultra Brightness YODN MSD 330w C18 8,000˚K , the Osram SIRIUS HRI 330 W ,8,000˚K is for Optional
Lifespan: Over 2,000 hours
Light Output: 795000 LUX @16 feet (2-degree beam); 14950 LUX @ 16 feet (33-degree beam)
Movement: 3 phase motor, Pan: 540°, Tilt: 270°. 8 bit or 16 bit control
Beam Angle: 0-33 degree, Motorized linear zoom
Color Wheel:
. Beam Angle: linear 2.5-20°
. Color Wheel: 13 colors + Open, color scroll
. Static Gobo Wheel: 13Metal Gobos + Open
. Rotating Gobo Wheel: 9 Rotating Gobos + Open
. Prism: Prims 1): 16 facet Circular Prism or 8 facet prism
Prism 2): 6 facet Linear Prism
. Frost: 0-100% fast linear Frost
. Zoom: 0-33 degree linear Zoom
. Focus: Linear Motorized Focus
. Dimming: 0-100% Linear dimming
. Strobe: 0-13 times per second
. Control Mode: 3 DMX MODE, 16/24/30 mode. Master/Slave, Built-in Program, sound-Actived mode.
. Voltage: AC90-240v,50/60hz(Auto-ranging)
. Max Power consumption: 550w
. Power Connector: PowerCon in & out
. DMX Connector: 3-pin and 5-pin DMX in & out
. Dimmension: 16.73” x 15.35” x 25.59” /425x390x650mm
. Weight: 52lbs (23.6kg)
• CE,Rosh,FCC approved.
